› 7.2V Li-ion battery pack
› For JVC HM600/650, LS300
(GY-HM250 Not compatible)
› Display remaining power info on camera viewfinder
› 47Wh / 6.6Ah capacity
› 4-level LED power indicator
› 7.2V Pole-tap DC output
› 5V/1A USB charging output
› Multiple circuit protections
JVC HM600/LS300 Compatible
Similar battery as SSL-JVC50, Display power info
S-8i50 is the replacement battery for SSL-JVC50, compatible with JVC
Camcorder HM600/650, LS300 and HMQ10. S-8i50 can exchange digital
info with the JVC cameras, and display remaining power info on the
camera viewfinder.
47Wh / 6.6Ah High Capacity
With 7.2V nominal voltage, the S-8i50 has 47Wh / 6.6Ah capacity, higher than the
original battery SSL-JVC50, and can run approx 4 hours on JVC GY-HM650 camcorder
when LCD monitor is on.
Build-in Pole-tap DC Output Socket
A 5.5/2.1mm pole-tap DC output socket is equipped on the side of S-8i50 battery, for DC
7.2V (Nominate) connection. You can connect on-camera LED light, monitor or wireless
transmitter on the pole-tap socket, and get power simultaneously with camera.
The Max power from the pole-tap is 40W, 5.5A.
Build-in 5V/1A USB
Use S-8i50 as Power Station to your cell phone!
It’s rather a fantastic function to have a USB socket
on the DV battery! Connect your smart phone or
pad to the USB socket, press the “Check” button,
and then the S-8i50 starts to output 5V/1A power
to charge your devices!
4-level LED Power Indicator
The S-8i50 battery has the 4-level LED power indicators to check the
battery remaining capacity. You can get a quick view of capacity
before using.
The “Check” button can also be used to trigger USB charging.
Easy Charging
The S-8i50 can be charged on SWIT Dual channel charger S-3602i or 4-ch charger LC-D421. It takes about 4 hours and 30 minutes to charge from empty to 100%.
Nominal Voltage | 7.2V |
Capacity | 47Wh, 6.6Ah |
Max output power | Total: 40W, 5.5A |
Pins: 25W,3.5A | |
| D-tap: 30W, 4A | |
| USB: 5W (5V / 1A) | |
Compatible cameras | JVC GY-HM600/650, LS300, HMQ10 |
Dimension | 76×70×43mm |
| Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C（Capacity and Max Load may decrease when operating below 0°） |
Net weight | Net 313g; With package0.35kg |
MSRP
MSRP
MSRP
1. Warranty Period
We provide 1 year conditional warranty for batteries.
2. Exclusions from Warranty Coverage
The following damages, malfunctions, failures, or safety incidents are not covered under warranty, and SWIT shall bear no liability therefor:
(1) Non-Compliance with User Manual
Operation, maintenance, or storage not in accordance with the instructions set forth in the User Manual; unauthorized disassembly, modification, or repair.
(2) Non-Compliant Charging Equipment and Practices
Use of non-original SWIT chargers or uncertified third-party charging accessories;
Use of third-party 5.5/2.1 barrel DC head charger of reversed polarity connections and cause any damage.
(3) Misuse and Physical Damage
Compression, puncture, dropping, impact, collision, water immersion, exposure to high temperatures or direct sunlight, or any other non-normal use not in accordance with the product's intended design.
(4) Use of Damaged or Defective Battery
Continued use of a battery that is damaged, leaking, or exhibiting abnormal overheating without prompt discontinuation.
(5) Natural Capacity Degradation
Reduction in battery capacity resulting from the natural aging process after a certain number of charge/discharge cycles.
(6) Improper Storage and Maintenance
Damage caused by improper storage practices that lead to extended deep discharge or prolonged zero-charge state of the battery.
(7) Force Majeure and Human Factors
Damage caused by irresistible factors (including but not limited to earthquake, fire, or lightning) or human factors.
(8) Non-Quality Defects
Any damage or breakdown not caused by the product's design, workmanship, or manufacturing quality.
(9) Liability Disclaimer
All risks and losses arising from non-compliant use shall be borne entirely by the user.
