Heavy Duty Gold Mount Battery

PB-R160A is an 160Wh Gold Mount battery, with dual housing heavy duty structure, 1.5m drop-off proof. Featured high load, fast charging and digital power info display for cameras, lights and field video production equipments.

1.5m Drop-off Proof

Dual housing + Robber cover

PB-R160A has innovative dual housing structure: the inner cell cage and outer anti-shock housing with rubber covers. The structure makes the battery quite strong, anti-shock. The battery can survive from 1.5 meters any angles drop-off.

160Wh / 11.1Ah Capacity

The largest capacity for airplane boarding

Consists of 18pcs high class 18650 battery cells, and reaches 160Wh / 11.1Ah high capacity, which is the largest capacity to board to airplane.
Can run approx 6 hours for normal ENG cameras, and approx 2 hours for ARRI ALEXA.

High Load for Cine Cameras

At least 200W / 16A load

PB-R160A provides at least 200W/16A high load even at 1% capacity, (Peak load up to 245W), to drive high power Cine cameras and on-camera devices together. The high load cells will also ensure battery life comparing to normal load batteries if long time full load output.

6A Fast Charging

Using SWIT 6A fast charger

PB-R160A supports 6A fast charging by SWIT PC-P461A fast charger, to save more than 50% charging time. The 160Wh PB-R160A battery can be charged from 0 to 80% after 1.5 hours, and fully charged within 2.5 hours.

8-LED Remaining Time Read

PB-R160A has the innovative 8-LED power indicators. When free or charging, the LEDs will indicate current capacity percentage, and when battery is discharging, the LEDs will display the remaining running time at the current discharging power, accurate to 15 minutes.

D-tap Socket

A D-tap DC output socket is equipped on the top side of the battery pack, to power the other on-camera equipments together.
The Max output current of D-tap is 10A.
