› 4-ch simultaneous fast charging
› Charge pure 28.8V B-mount batteries
› Charge 14.4V/28.8V Bi-voltage B-mount batteries
› 33.6V/3A 100W super fast charging
› 3.5-inch color LCD info display
› Battery cycle times display
› Top large charging indicators
![](https://www.swit.cc/uploads/image/PC-P461B/PC-P461B-5.jpg)
![](https://www.swit.cc/uploads/moimage/mPC-P461B/PC-P461B-5.jpg)
4x100W Super Fast Charger
PC-P461B can charge 4x B-mount batteries simultaneously at 33.6V/3A, 100W per channel super fast charging speed, save up to 60% charging time comparing to normal chargers.
Compatible with pure 28.8V B-mount batteries and 14.4V/28.8V bi-voltage B-mount batteries.
![](https://www.swit.cc/uploads/image/PC-P461B/PC-P461B-6.jpg)
![](https://www.swit.cc/uploads/moimage/mPC-P461B/PC-P461B-6.jpg)
Charging Time
To charge 4x 290Wh B-mount batteries, the
PC-P461B will take only 2 hours 30 minutes
to charge to 80%, and take 3 hours 50 minutes
to fully charge.
![](https://www.swit.cc/uploads/image/PC-P461B/PC-P461B-7.jpg)
![](https://www.swit.cc/uploads/moimage/mPC-P461B/PC-P461B-7.jpg)
3.5-inch Color LCD
PC-P461B provides a 3.5-inch color LCD panel
to display charging progress, charging current
and voltage, and battery cycle times of each
channel.
![](https://www.swit.cc/uploads/image/PC-P461B/PC-P461B-8.jpg)
![](https://www.swit.cc/uploads/moimage/mPC-P461B/PC-P461B-8.jpg)
Top Charging Indicators
Besides LCD screen info, you can check the
charging status at a glance by the 4 large size
indicators on the top of the charger.
Red on: 0-80%
Green flashing: 81%-99%
Green on: 100% fully charged
Red flashing: Charging error, check LCD info
![](https://www.swit.cc/uploads/image/PC-P461B/PC-P461B-9.jpg)
![](https://www.swit.cc/uploads/moimage/mPC-P461B/PC-P461B-9.jpg)
Light Weight and Portable
The 4 channel fast charger PC-P461B has minimized
the size and weight, and the new handle design makes
the charger solid and easy to carry.
Power | Max 450W |
Input | AC100V-240V 50/60Hz |
Output | DC 33.6V, 3A×4 |
Applicable battery | B-mount battery |
Dimensions | 330×153×162mm |
Net weight | Net 2.43kg; With package 3.3kg |
