S-8082A 95Wh Gold Mount Battery Pack

›  Li-ion, 14.4V, 95Wh capacity

›  D-tap output socket

›  4-level LED power indicator

›  Gold mount connection

›  Not restricted by IATA

›  Multiple circuit protections


Features

Gold Mount Camera Battery

S-8082A is the AntonBauer gold mount rechargeable Li-ion battery pack for professional video cameras.It’s compact design, smaller in size.

95Wh / 6.6Ah Capacity

Consists of 12pcs 18650 battery cells, and reaches 95Wh/6.6Ah high capacity.Run approx 3 hours for normal 30W ENG cameras, and not restricted by IATA air transportation regulations.

AntonBauer Gold Mount Connection

S-8082A is compatible with AntonBauer Gold mount type power system and we adopt the high quality connection bolts that ensure the reliable mounting.

Build-in D-tap DC Output Socket

A D-tap DC output socket is equipped on the top side of S-8082S battery, for DC14.4V (Nominate) connection, such as on-camera lights, monitors, wireless transmitter, etc.
The Max Power from D-tap is 120W, 10A.

4-level LED Power Indicator

On the side of the battery, there’re 4-level LED power indicators to check the battery remaining capacity. You can get a quick view of capacity before using.

无标题文档

Nominal Voltage

14.4V

Capacity

95Wh/6.6Ah

Max output power

In total:150W

Electrodes:150W,12A
D-tap:120W,10A

Mount Type

Gold mount

Charging Temperature

0-40°C
     Discharging Temperature-20°C-50°C(Capacity and Max Load may decrease when operating below 0°

Net weight

710g

Dimensions

134×88×54mm
Basic Package

MSRP

$8222

MSRP

MSRP

  • S-8082S

    95Wh V-mount Battery Pack

    Adpot high performance Li-ion battery cells with intelligent safety protection circuit; D-tap output, LED power indicators

    $8222
  • S-8083A

    130Wh Gold Mount Battery Pack

    Adpot high performance Li-ion battery cells with intelligent safety protection circuit; D-tap output, LED power indicators

    $8222
  • PC-P430S

    4-ch V-mount Fast Charger

    3A×4 fast charging current; AC-DC adapter output, LED charging indicators

    $8222
  • S-3812A

    2-ch Gold mount Super Fast Charger

    2-ch simultaneous charging, Max 6A fast charging, support AC-DC and Battery-DC adaptor output, LCD display working status

    $8222
