CIMO-290S 290Wh USB-C OLED info Cine V-mount Battery

› Cine style V-mount battery

› 290Wh/20.1Ah large capacity

› 250W/20A constant high load, 335W peak

› 2×D-tap output & charging input

› 1x USB-A 5V/9V 2A 18W output

› 1x USB-C 65W output & 60W input

› OLED remaining run time display

› Rear LED torch for dark environment

› Strong housing 1.2m drop-off proof

› BMS multiple circuit protections

Features

CINE V-Mount Battery

The CIMO series cine class V-mount batteries featured high power load, 2× D-tap, 65W USB-C, OLED power info display, battery life inspection and 1.2m drop-off proof for professional cinematographers.

14.4V, 290Wh Capacity

CIMO-290S consists of 24pcs ternary lithium cells, 14.4V nominal voltage, 290Wh, 20.1Ah large capacity.

The ternary lithium cells provide higher energy density, achieve higher capacity with a smaller size, and excellent low-temperature performance, capable of supplying power under -20°C cold environment.

250W Constant High Load, 335W Peak

CIMO-290S outputs at least 250W/20A high load even at 1% capacity (Peak load up to 335W), to drive high power Cine cameras and on-camera devices together. The high load cells will also ensure battery life comparing to normal load batteries if long time full load output.

100W 6A Fast Charging

CIMO-290S supports 100W/6A fast charging by SWIT PC-P461S / MATRIX-S8 / S-3812S chargers, twice the charging speed, and the 6A fast charging will not affect the lifespan of ternary lithium cells.

The 290Wh battery can be charged from 0 to 80% after 2.5 hours, and fully charged within 3.8 hours.

OLED Power Info / Health Level Display

CIMO-290S battery provides an OLED screen to display battery status and power information, includes power percentage, remaining running time, and long press the power check button to display battery cycle times, health level for battery management.

2×D-tap, USB-A & USB-C

CIMO-290S provides with
2x D-tap 250W in total;
1x USB-A 5V/9V 2A out;
1x USB-C 60W input and 65W output
for various on-camera devices.

USB-C 65W Output

The USB-C port of CIMO-290S outputs 5V/9V/12V/15V 3A, 20V(Max) 3.25A, 65W high power for laptops and various smart devices, with BC1.2, QC2.0/3.0, FCP, SCP, PD2.0/3.0 universally compatible protocols.

USB-C 60W Charging Input

The battery can also be charged by USB-C charger of PD2.0/3.0 ≥60W power, fully charged within 6.6   hours.

* Please note that<60W low power USB-C chargers are unable to charge this battery.

LED Torch

You can double press the Power Check button to switch on LED torch on the rear side of the battery, to help you to find V-mount plate in dark production environment.

Double press the Power Check button again to switch the light off, and it will be automatically switched off after 60 seconds.

1.2 meters Drop-off Proof

CIMO series batteries are dual housing designed and can survive from 1.2 meters drop-off at any angles, strong and reliable for filmmakers.

Battery plate

V-mount

Nominal voltage

14.4V

Capacity

290Wh, 20.1Ah

Power Load

250W, 20A constant; 335W peak

Power IN&OUT

Electrodes: 250W 20A out, 16.8V 8A(Max) in

D-tap×2: (Plug 1×D-tap) 250W 20A out

(Plug 2×D-tap) 250W 20A out in total

Charging through D-tap: 16.8V 8A(Max) in

USB-A: 5V/9V(Max) 2A out, 18W

USB-C out: 65W, 5V/9V/12V/15V/20V(Max)=3.25A

BC1.2, PD2.0/3.0, QC2.0/3.0, FCP, SCP

USB-C charging in:

USB-C to C Charger Request - PD2.0/3.0, Power ≥60W

USB-A to C Charger Request - 5V only

Dimension

144×100×67mm

      Charging Temperature0-40°C
      Discharging Temperature

-20°C-50°C

Net weight

Net 1.509kg; With package 1.568kg
