LA-WR8 Pocket Wireless DMX Console

›  Pocket size portable DMX controller

›  2.4G wireless, quick connection

›  400m (LOS) transmission distance

›  Control all standard DMX512 lights

›   8-ch x 7 groups control channels

›   2x AA batteries or USB power

Features

Pocket Wireless DMX

LA-WR8 is a portable wireless DMX controller for field light kit application, compatible with all standard DMX512 protocol lights, to get rid of complex DMX cable work and large DMX console, and makes the field light kit control easier and quicker.
* The “SkyPanel” light indicated in this picture is a product of ARRI Group, and is one of the lights that this wireless DMX controller is compatible with.



2.4G Wireless Quick Connect

Adopt 2.4G wireless transmission, quick connecting, plug and play, anti-interference, 400 meters transmission distance in line of sight.
One controller can be connected with multiple light adaptors.



8-ch×7 Groups DMX512 Control

LA-WR8 adopts standard DMX512 protocol, 8 faders and 7 groups switching by 7 colors indicator. (Totally 56 DMX channels) Switch the controller group color the same as light adaptors, and they can be connected and controlled.

Standard 5-pin DMX connector

The light adaptor provides standard 5-pin DMX connector, compatible with all standard 5-pin DMX lights.

Power Supply

The Controller can be powered by 2x AA batteries, continuously 4 hours working. Support sleep mode if no operation after 1 minute. The Controller supports Micro USB power input as well. You can use USB power bank to power the controller.
The Light Adaptor is powered by USB, only 0.5W power. The professional lights like Skypanel, SWIT PL-E series, FL-C series have USB socket on the light.

The Controller

Model

LA-WR8

Wireless

2.4G transmission

Distance

400 meters (Line-of-Sight)

Input Voltage

2x AA batteries or 5V Micro USB

Power Consumption

1W

Dimension

184mm×84mm×22mm

Weight

Approx. 274g

The Light Adaptor

Model

LA-WR8-R

Wireless

2.4G transmission

Distance

400 meters (Line-of-Sight)

Input Voltage

5V Micro USB

Power Consumption

0.5W

Dimension

110mm×70mm×12mm

Weight

Approx. 47g
Basic Package

MSRP

$8222

MSRP

$8222

MSRP

$8222

  • LA-WR8-R Receiver x3, with USB cables

  • LA-WR8 Controller x1, with USB cable

  • LA-WR8-R

    Wireless DMX Receiver, connect with 5-pin DMX port of a light, and powered by USB. Provide USB cable together.
  • S-2840

    400W RGBW LED Panel Light

    560pcs RGBW LED, CCT/HSL/RGB modes, Rosco/Lee GELs, IOS/Android APP control

    $8222
  • PL-E90D

    90W Portable Bi-color SMD Panel LED light

    480pcs bright SMD LEDs, 90W, DMX control, 2200Lux@1m bright, 2700K-6500K adjustable, Super thin and portable.

    $8222
  • PL-E60D

    60W Portable Bi-color SMD Panel LED Light

    320pcs bright SMD LEDs,DMX control, equally spread surface light, 60W, 1500Lux@1m bright, 2700K-6500K adjustable,DMX control, Super thin and portable.

    $8222
  • FL-C60D

    60W Bi-color Fresnel COB-LED Light

    25000Lux super bright, 15°-60° beam angle, 2700K-8000K adjust, Super high CRI 95, TLCI 97, silent mode, DMX control

    $8222
