◆ SONY NP-F series battery comparable
◆ 7.2V nominal voltage Li-ion battery
◆ 65Wh / 9.02Ah capacity
◆ 30W / 4A constant power load
◆ Built-in 12V reg. D-tap output
◆ Built-in 25W USB-C input and output
◆ 4-level LED power indicator
◆ Display remaining power info on camera viewfinder
◆ Multiple circuit protections
65Wh NP-F Battery
with D-tap and USB-C
LB-SF65C is a new 65Wh large capacity NP-F
type DV battery with regulated 12V D-tap
output and 25W USB-C in/out, widely
compatible with pro-video gears.
* Please Note this battery can't power SONY cameras.
65Wh Large Capacity
LB-SF65C consists of 6pcs battery cells and has 65Wh/9020mAh large capacity to keep your video devices powered for longer time. The constant power load is 30W/4A.
Reg. 12V D-tap Output
The LB-SF65C NP-F battery provides a D-tap power
output socket of regulated 12V voltage, widely
compatible with various kinds of video devices.
* The D-tap has 7.2V to 12V (Reg.) conversion and
it’ s not allowed to charge input via this D-tap socket.
USB-C 25W Output
Fast Charging iPhone 12/13
LB-SF65C provides a USB-C sockets, supports 5V 3A, 9V
2.8A, 12V 2.1A, 15V 1.7A, 20V 1.3A, 25W power output
to fast charge iphone 12/13 and all kinds of USB-C smart
phones or tablets, with BC1.2, PD2.0/3.0, QC2.0/3.0,
FCP, SCP multiple protocols.
USB-C 25W Charging Input
You can also charge LB-SF65C by USB-C charger.
Supports PD 5V 3A, 9V 2.8A, 12V 2.1A, 15V 1.7A,
20V 1.3A, 25W power input, which means you can
fully charge the 65Wh battery within 3.5 hours.
4-level Power Indicator
Press the power check bottom, the 4-level
LEDs indicates remaining power percentage.
4-way Charging
LB-SF65C can be charged by any NP-F charger.
Use SWIT LC-D421 4-way charger you can
charge 4 batteries simultaneously, and fully
charging within 5 hours.
Nominal Voltage | 7.2V |
Capacity | 65Wh, 9.02Ah |
Max power load | 30W, 4A |
D-tap | 12V (reg.) 1.7A, 20W |
USB-C | 25W input: 5V 3A, 9V 2.8A, 12V 2.1A, 15V 1.7A, 20V 1.3A 25W output: 5V 3A, 9V 2.8A, 12V 2.1A, 15V 1.7A, 20V 1.3A BC1.2, QC2.0/3.0, PD2.0/3.0, FCP, SCP |
Original batteries | SONY NP-F770, NP-F970 |
Dimension | 71×39×76mm |
| Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C (Capacity and Max Load may decrease when operating below 0°) |
Net weight | Net 345g; With package0.35kg |
MSRP
MSRP
MSRP
1. Warranty Period
We provide 1 year conditional warranty for batteries.
2. Exclusions from Warranty Coverage
The following damages, malfunctions, failures, or safety incidents are not covered under warranty, and SWIT shall bear no liability therefor:
(1) Non-Compliance with User Manual
Operation, maintenance, or storage not in accordance with the instructions set forth in the User Manual; unauthorized disassembly, modification, or repair.
(2) Non-Compliant Charging Equipment and Practices
Use of non-original SWIT chargers or uncertified third-party charging accessories;
Use of third-party USB-C chargers without compliant PD protocols;
This battery doesn't support charging via D-tap, use any D-tap charger to charge the battery and cause any damage.
(3) Misuse and Physical Damage
Compression, puncture, dropping, impact, collision, water immersion, exposure to high temperatures or direct sunlight, or any other non-normal use not in accordance with the product's intended design.
(4) Use of Damaged or Defective Battery
Continued use of a battery that is damaged, leaking, or exhibiting abnormal overheating without prompt discontinuation.
(5) Natural Capacity Degradation
Reduction in battery capacity resulting from the natural aging process after a certain number of charge/discharge cycles.
(6) Improper Storage and Maintenance
Damage caused by improper storage practices that lead to extended deep discharge or prolonged zero-charge state of the battery.
(7) Force Majeure and Human Factors
Damage caused by irresistible factors (including but not limited to earthquake, fire, or lightning) or human factors.
(8) Non-Quality Defects
Any damage or breakdown not caused by the product's design, workmanship, or manufacturing quality.
(9) Liability Disclaimer
All risks and losses arising from non-compliant use shall be borne entirely by the user.
