› Li-ion battery of 7.2V nominal voltage
› For Panasonic AU-EVA1, AG-DVX200, etc
› Comparable to Panasonic VW-VBD58
› Comparable to Panasonic AG-VBR59
› Can be charged by Panasonic DE-A88
› Can be charged by SWIT S-3602D
› 70Wh / 9800mAh capacity
› 4-level LED power indicator
› 7.2V Pole-tap DC output
› 5V/1A USB charging output
› Multiple circuit protections
Panasonic EVA1,DVX200 Compatible
Similar battery for Panasonic VW-VBD58/AG-VBR59
S-8D98 is the replacement battery for Panaso-
nic VW-VBD58 or AG-VBR59, compatible with
Panasonic AU-EVA1, AG-DVX200 and AJ-PX-
270/285, etc.
70Wh/9800mAh Capacity
With 7.2V nominal voltage, the S-8D98 has
70Wh / 9800mAh capacity, and can run more than 3 hours on AU-EVA1
camcorder.
Build-in Pole-tap DC Socket
For DC output or Charging input
A 5.5/2.1mm pole-tap DC output socket is equipped on the S-8D98 battery, for DC 7.2V (Nominate) connection. You can connect
on-camera LED light, monitor or wireless transmitter on the pole-tap socket, and get power simultaneously with camera.
The Max power from the pole-tap is 30W, 4A.
Build-in 5V/1A USB Socket
Use S-8D98 as Power Station to your cell phone!
It’s rather a fantastic function to have a USB socket on the
DV battery!
Connect your smart phone or pad to the USB socket, press
the “Check” button, and then the S-8D98 starts to output
5V/1A power to charge your devices!
4-level LED Power Indicator
The S-8D98 battery has the 4-level LED power
indicators to check the battery remaining capacity.
You can get a quick view of capacity before using.
Easy Charging
The S-8D98 can be charged on Panasonic original charger
DE-A88, and SWIT also provides the Dual channel charger
S-3602D or 4-ch charger LC-D421 for S-8D98, will take about 6 hours to charge from
empty to 100%.
Nominal Voltage | 7.2V |
Capacity | 70Wh, 9800mAh |
Max output power | Total: 30W, 4A |
Pins: 25W,3.5A | |
| Pole-tap: 30W, 4A | |
| USB: 5W (5V / 1A) | |
Compatible cameras | Panasonic AU-EVA1 |
| Panasonic AG-DVX200 | |
| Panasonic AJ-PX270 | |
Panasonic AJ-PX285 | |
Dimension | 41×70×83mm |
| Charging Temperature | 0-40°C |
| Discharging Temperature | -20°C-50°C（Capacity and Max Load may decrease when operating below 0°） |
Net weight | Net 337g; With package0.35kg |
MSRP
$8222
MSRP
$8222
MSRP
$8222
We provide 1 year conditional warranty, and the following damages/issues are not covered under warranty:
(1) Any damage or breakdown caused by use, maintenance, or storage not according to the User Manual’s instructions, or disassemble, repair without authorization of SWIT.
(2) Battery performance declines, cannot be charged or any charging errors caused by using third-party chargers.
(3) Battery capacity naturally decreased after a certain cycle times of charging and discharging.
(4) The capacity loss caused by over 6-month’s storage, and not charging the battery to re-active it during the period.
(5) Any damage caused by irresistible factors (such as earthquake, fire, lightning etc.) or human factors.
(6) Any damage or breakdown not caused by the product’s design, workmanship, or manufacturing quality, etc.
