LA-R960 96-ch DMX512 Light Console
› Standard DMX512 console with isolater
› 48x channel sliders with A/B switch to 96-ch
› 12x submaster slider and 1x master slider
› RDM remote control support
› LCD display DMX values of each channel
› Flash control buttons for each slider
96-ch DMX Console
LA-R960 is a Zero-basis operatable standard DMX512 light console of 48 channel sliders and Page A/B switch to control 96 channels in total.
Interface
LA-R960 supports AC 88-256V 50/60Hz input, RS232 remote control, USB-A power out and firmware update, DMX sockets of both 3-pin male and female.
Submaster and Master Control
LA-R960 provides 12x Submaster sliders with A/B/C pages switch to group any of the 48 channels, and a Master slider to control all connected lights. The LCD displays exact values of every DMX channel. Support RDM control.
Channel | 96 |
Submaster | 12 |
Master | 1 |
DMX | 3-pin XLR, DMX512 and RDM |
RDM | Yes |
Power | AC88～256V 50/60Hz |
Dimension | 498x 420 x 115 mm |
Weight | 7.3kg |
